Design of CPLD experiment set

ivDESIGN OF CPLD EXPERIMENT SET(M.Sc. Thesis)Salim KIYMAZGAZI UNIVERSITYINSTITUTE OF SCIENCE AND TECHNOLOGYSeptember 2005ABSTRACTIn this thesis, the circuit design of CPLDs produced by XILINX, is studied byusing WebPACK ISE program produced by the same company. Designs aredone by using VHDL programming language or schematic methods. Simulationof designs are studied by using MXE Simulator Program. Design of applicationswill be easily transferred to CPLD on the electronic circuit and will be reloadedagain after doing the required changes on the design to CPLD. The studies doneon the computers provide several advantages such as time, workforce and costfor digital electronic applications.Science Code :626.04.01Key Words :Xilinx, CPLD, DesignPage Number :126:Asist. Prof. Dr. M. Rahmi CANALAdviser
