Electromagnetic fields produced by high voltage electrical overhead lines

With the invention of electricity produced in power plants, energy transmission, distribution lines and substations have been established to provide users with transmission of electric energy. Therefore, the electromagnetic fields (EMF) has surrounded the people's living environment. In this study, electromagnetic field calculations have been made in energy transmission line and transformer centers.Calculations can be done separately around high voltage electrical overhead lines, the field calculations has been carried out at the desired point the bottom of line.In addition, through Narda EFC-400 LF simulation program, EMF calculations were made in a sample substation. Results are explained with the help of the graphics.
